HOM4-R/ T/ RT Optical Monitor

Optorun Main Products

Category: Optorun Tags: Component, Optical Monitor

Description

Product Description

Wide Range Optical Monitor

HOM4 is an optical thickness meter for wide range optical filter deposition system. It covers same wavelength as HOM2-RT-S1.

Features

Monitoring wavelength can be automatically controlled from 350 – 2400nm.
Space-saving design with the modification of monochromator. (installation space is as same as that for HOM2 series.)
Transmittance and reflectance monitoring mode are available and can be switched automatically.

Specifications

Model	HOM4-R	HOM4-T	HOM4-RT
Wavelength range	350 – 2400nm
Light Source	Halogen lamp
Power Requirements	AC100V ± 10%, 50/60Hz
